- Phidgets NEMA17 – 1.8 Degree – 1.68A Stepper – 51:1 Gearbox
- Enhances torque with 51:1 gearbox
- Delivers 48 kg-cm continuous torque
- Operates at precise 0.035° steps
- Connects to Phidgets stepper controller
- Runs at max speed of 20 RPM
The Phidgets NEMA17 – 1.8 Degree – 1.68A Stepper – 51:1 Gearbox is a sophisticated bipolar stepper motor designed for precision and efficiency. It features a planetary gearbox that significantly enhances its torque capabilities, providing 48 kg·cm of torque at low speeds. The motor’s step angle is refined to approximately 0.035° after the gearbox, allowing for precise control in applications requiring fine adjustments. This motor is equipped with a rear shaft, enabling the attachment of an encoder or shaft coupler for enhanced functionality.
The motor operates at a current rating of 1.68A and is capable of producing a maximum torque of 180 kg-cm. However, it is important to note that the gearbox is rated for continuous torque of 48 kg-cm, and exceeding this limit may reduce the motor’s lifespan. The motor is designed to be used with a constant current or chopper drive controller, such as a Phidget stepper controller, to ensure optimal performance and longevity.
Note: Connecting the motor directly to a power supply will destroy the motor and void the warranty.
- 1x Phidgets NEMA17 – 1.8 Degree – 1.68A Stepper – 51:1 Gearbox
- Torque rating of 48 kg-cm
- 51:1 planetary gearbox
- Step angle of 1.8 degrees (0.035 degrees after gearbox)
- Rated current of 1.68A
- Compatible with Phidgets stepper controller
- Maximum motor speed of 20 RPM
- Recommended voltage of 24 V DC
- Gear ratio of 50 4397⁄4913 : 1
