Description
- Waveshare 1.54″ E-Ink Raw Display Panel, 200×200, 3-Color
- Features 200×200 resolution, 3-color display
- Supports SPI interface for communication
- Offers ultra-low power consumption
- Maintains content without power
- Includes development resources and manual
The Waveshare 1.54″ E-Ink Raw Display Panel, 200×200, 3-Color is an advanced display solution featuring a 200×200 resolution and supports red, black, and white colors. It integrates an embedded controller and communicates via an SPI interface. This display is renowned for its ultra-low power consumption, requiring power only during refresh cycles, and its ability to maintain a clear display without electricity. Its wide viewing angle and no-backlight design make it suitable for applications such as shelf labels and industrial instruments. Development resources and manuals are available for ease of integration.
- 1x Waveshare 1.54″ E-Ink Raw Display Panel, 200×200, 3-Color
- Outline dimensions: 31.8 x 37.32 x 1.05 mm
- Display size: 27.6 x 27.6 mm
Website
- Operating voltage: 3.3V
- Interface: 3-wire SPI, 4-wire SPI
- Dot pitch: 0.138 × 0.138
- Resolution: 200
- Display colors: red, black, white
- Grey level: 2
- Full refresh time: 14 seconds
- Refresh power: 26.4mW (typical)
- Standby power: less than 0.017mW
- Viewing angle: greater than 170°
- No backlight; retains last displayed content for an extended period even when powered down
- Ultra-low power consumption; power is primarily needed for refreshing
- Includes development resources and manual (driver board schematic, examples for Raspberry Pi/Jetson Nano/STM32)
