- ServoCity 12V Heavy-Duty Linear Actuator (33lb Thrust, 1.7″/sec, 6″ Stroke)
- Delivers 33lb dynamic thrust, 6″ stroke
- Features a robust metal gear train
- Incorporates a 10KΩ potentiometer for feedback
- Operates within -26°C to +65°C
- Rated IP54 for environmental protection
The ServoCity 12V Heavy-Duty Linear Actuator (33lb Thrust, 1.7″/sec, 6″ Stroke) is engineered to deliver reliable performance with a 6-inch stroke and a speed of 1.7 inches per second under no load conditions. It provides a dynamic thrust capacity of 33 pounds and can sustain a static load of up to 500 pounds. This actuator is powered by a 3 Pole Ferrite motor and incorporates a 10KΩ potentiometer for precise feedback. The construction includes a robust metal gear train complemented by a nylon pinion, and it utilizes a straight cut spur gearbox with a 5:1 gear ratio. Designed to operate within a voltage range of 6V to 12V, it is rated IP54, ensuring suitability for diverse environmental conditions. The actuator’s duty cycle is structured at 25% on and 75% off, featuring a lead screw with a 3mm pitch and single thread. The potentiometer offers a tolerance of ± 5% and a linearity of ± 0.25%, with a feedback density of 1.66KΩ per inch. It is equipped with a 24-inch wire length and functions efficiently within an operating temperature range from -26°C to +65°C.
- 1x ServoCity 12V Heavy-Duty Linear Actuator (33lb Thrust, 1.7″/sec, 6″ Stroke)
- Stroke: 6″
- Retracted Length: 5.90″
- Extended Length: 11.69″
ZIP File
- ServoCity 12V Heavy-Duty Linear Actuator (33lb Thrust, 1.7″/sec, 6″ Stroke) – STEP File
- Operating temperature: -26°C to +65°C
- Motor type: 3-pole ferrite
- Feedback style: 10KΩ potentiometer
- Gear material: Metal gear train, nylon pinion
- Wire length: 24 inches
- Voltage range (recommended): 6V to 12V
- Speed (no load): 1.70 inches per second
- Gearbox style: Straight cut spur
- Gear ratio: 5:1
- Speed (max load): 1.37 inches per second
- Dynamic thrust: 33 lbs
- Static load: 500 lbs
- Current drain (no-load): 800mA
- Current drain (max load): 3.8A
- Current drain (stall): 15A
- Potentiometer tolerance: ± 5%
- Feedback density: 1.66KΩ per inch
- IP rating: IP54
- Duty cycle: 25% on, 75% off
- Lead screw type: 3mm pitch, single thread
- Potentiometer linearity: ± 0.25%
