Description
- ServoCity 12V Heavy-Duty Linear Actuator (112lb Thrust, 0.6″/sec, 4″ Stroke)
- Engineered for robust performance in demanding applications
- Operates efficiently at a voltage range of 6V to 12V
- Ensures durability with metal gear train and nylon pinion
- Provides precise control with 10KΩ potentiometer feedback
- Designed for operation in temperatures from -26°C to +65°C
The ServoCity 12V Heavy-Duty Linear Actuator (112lb Thrust, 0.6″/sec, 4″ Stroke) is engineered for robust performance in demanding applications. It features a 4-inch stroke and operates efficiently within a voltage range of 6V to 12V. The actuator is equipped with a 3 Pole Ferrite motor and a metal gear train complemented by a nylon pinion, ensuring durability and reliability. It provides a dynamic thrust of 112 lbs and can handle a static load capacity of up to 500 lbs. The actuator’s no-load speed is 0.60 inches per second, while the maximum load speed is 0.39 inches per second. It incorporates a 10KΩ potentiometer feedback style with a tolerance of ± 5% and a feedback density of 2.5KΩ per inch, offering precise control and positioning. The device is designed to operate within a temperature range of -26°C to +65°C and has an IP54 rating, indicating protection against dust and water splashes. The duty cycle is set at 25% on and 75% off, optimizing performance and longevity. Note: Ensure proper handling to avoid exceeding the current drain limits, particularly the stall current of 15A.
- 1x ServoCity 12V Heavy-Duty Linear Actuator (112lb Thrust, 0.6″/sec, 4″ Stroke)
- Stroke: 4″
- Retracted Length: 9.69″
- Extended Length: 13.62″
ZIP File
- ServoCity 12V Heavy-Duty Linear Actuator (112lb Thrust, 0.6″/sec, 4″ Stroke) – STEP File
- Operating temperature: -26°C to +65°C
- Motor type: 3-pole ferrite
- Feedback style: 10KΩ potentiometer
- Gear material: Metal gear train, nylon pinion
- Wire length: 24 inches
- Voltage range (recommended): 6V to 12V
- Speed (no load): 0.60 inches per second
- Gearbox style: Straight cut spur
- Gear ratio: 20:1
- Speed (max load): 0.39 inches per second
- Dynamic thrust: 112 lbs
- Static load: 500 lbs
- Current drain (no-load): 700mA
- Current drain (max load): 3.8A
- Current drain (stall): 15A
- Potentiometer tolerance: ± 5%
- Feedback density: 2.5KΩ per inch
- IP rating: IP54
- Duty cycle: 25% on, 75% off
- Lead screw type: 3mm pitch, single thread
- Potentiometer linearity: ± 0.25%
