Description
- ServoCity 12V Heavy-Duty Linear Actuator (112lb Thrust, 0.6″/sec, 8″ Stroke)
- Delivers 112 lb thrust with 8″ stroke
- Operates at 0.60″ per second no load
- Features 10KΩ potentiometer feedback
- Includes durable metal gear train
- Designed for -26°C to +65°C operation
The ServoCity 12V Heavy-Duty Linear Actuator (112lb Thrust, 0.6″/sec, 8″ Stroke) is engineered to deliver robust performance with an 8-inch stroke and a dynamic thrust capacity of 112 pounds. It operates efficiently at a speed of 0.60 inches per second under no load conditions. This actuator is powered by a 3 Pole Ferrite motor and incorporates a 10KΩ potentiometer for precise feedback. The construction includes a metal gear train complemented by a nylon pinion, and it features a straight cut spur gearbox with a 20:1 gear ratio. Designed to function within a voltage range of 6V to 12V, it is equipped with an IP54 rating, ensuring its adaptability to diverse environmental conditions. The actuator utilizes a lead screw with a 3mm pitch, single thread, and maintains a duty cycle of 25% on and 75% off. It is capable of operating in temperatures ranging from -26°C to +65°C, making it suitable for a wide range of applications. Note: Ensure proper handling to avoid exceeding the specified duty cycle and environmental conditions.
- 1x ServoCity 12V Heavy-Duty Linear Actuator (112lb Thrust, 0.6″/sec, 8″ Stroke)
- Stroke: 8″
- Retracted Length: 7.87″
- Extended Length: 13.70″
- Center to Center Length: 21.57″
ZIP File
- ServoCity 12V Heavy-Duty Linear Actuator (112lb Thrust, 0.6″/sec, 8″ Stroke) – STEP File
- Operating temperature: -26°C to +65°C
- Motor type: 3-pole ferrite
- Feedback style: 10KΩ potentiometer
- Gear material: Metal gear train, nylon pinion
- Wire length: 24 inches
- Voltage range (recommended): 6V to 12V
- Speed (no load): 0.60 inches per second
- Gearbox style: Straight cut spur
- Gear ratio: 20:1
- Speed (max load): 0.39 inches per second
- Dynamic thrust: 112 lbs
- Static load: 500 lbs
- Current drain (no-load): 700mA
- Current drain (max load): 3.8A
- Current drain (stall): 15A
- Potentiometer tolerance: ± 5%
- Feedback density: 1.25KΩ per inch
- IP rating: IP54
- Duty cycle: 25% on, 75% off
- Lead screw type: 3mm pitch, single thread
- Potentiometer linearity: ± 0.25%
