Description
- Phidgets LCD Screen 2×40 (5.5mm Characters)
- Displays two rows of 40 characters
- Adjusts contrast and backlight brightness
- Connects with Phidgets LCD adapter
- Operates -20°C to 70°C
- Compact 152.5×16.5mm viewing area
The Phidgets LCD Screen 2×40 (5.5mm Characters) is a sophisticated backlit LCD display module designed to present information clearly and efficiently. It features two lines, each capable of displaying 40 characters, providing ample space for detailed text output. The viewing area measures 152.5 x 16.5mm, ensuring that the display is both compact and easy to read.
This LCD screen offers adjustable contrast and backlight brightness, allowing users to tailor the display settings to suit various lighting conditions and personal preferences. It is designed to connect seamlessly with a Phidgets 1204 LCD adapter, facilitating straightforward integration into existing systems.
The display is engineered for reliability and performance, operating within a temperature range of -20°C to 70°C, making it suitable for a wide array of environments. A 30cm cable is included to ensure convenient connectivity.
- 1x 30cm Cable
- Viewing area: 152.5 x 16.5 mm
PDF File
- Phidgets LCD Screen 2×40 (5.5mm Characters) – Data Sheet
ZIP File
- Phidgets LCD Screen 2×40 (5.5mm Characters) – 3D Step File
- Displays two rows of 40 characters
- Adjustable LCD contrast and backlight brightness
- Connects to a Phidgets 1204 LCD adapter
- Dots per character: 5 x 8
- Backlight current consumption maximum: 300 mA
- Controlled by LCD adapter
- Current consumption maximum: 3 mA
- Supply voltage: 5 V DC
- Operating temperature range: -20 °C to 70 °C
