Description
- Phidgets DC Current Transducer ±100A
- Measure bidirectional current up to ±100A
- Features hall-effect technology for precise measurement
- Compatible with Phidget 1145 adapter
- Ensures accurate readings with 200 mA resolution
- Operates within -10°C to 80°C for various environments
The Phidgets DC Current Transducer ±100A is a sophisticated bi-directional current sensor designed to measure direct current up to ±100 amps. Utilizing hall-effect technology, this transducer allows for the measurement of current by simply threading a wire through its window. This feature enables the sensor to detect current flow in both directions, making it particularly useful in applications where the current direction may vary, such as monitoring both the output and charging current of a battery.
The transducer is compatible with the Phidget 1145 adapter, facilitating seamless integration into various systems. It provides a reliable method for converting output voltage to current using a specific formula, ensuring accurate readings. The device is engineered to deliver precise measurements with a resolution of 200 mA and a maximum measurement error of 1%.
Note: Ensure proper handling and installation to avoid potential hazards associated with electrical measurements.
- 1x Phidgets DC Current Transducer ±100A
- Wire Window Size: 23 mm
ZIP File
- Phidgets DC Current Transducer ±100A – 3D Step File
- Measures DC current from -100 to 100 Amps
- Connects to the Phidget 1145 adapter
- Current measurement resolution: 200 mA
- Maximum measurement error: 1%
- Maximum sensor response time: 7 μs
- Supply voltage: ±12 V DC
- Maximum current consumption: 25 mA
- Minimum output voltage: 0 V DC
- Maximum output voltage: 5 V DC
- Operating temperature range: -10 °C to 80 °C
