Description
Description
- FingerTech FT1806 750KV Brushless Motor
- Features high-performance custom-wound design
- Eliminates weak points with E-clip-free design
- Optimizes performance on 2-4S lipoly batteries
- Supports flexible wire connections for setup
- Fits various builds with compact dimensions
The FingerTech FT1806 750KV Brushless Motor is a high-performance custom-wound outrunner, ideal for replacing battle-damaged motors or for use in custom creations. It features a unique design without an E-clip, eliminating weak points in the shaft. With a KV rating of 750KV and a rated voltage of 20V, this motor performs optimally on 2-4S lipoly batteries. It supports a rated current of 10A and a maximum current of 10A at 12V, with a motor resistance of 0.15 ohm. The motor’s efficiency peaks at 58.68% at a power of 72W and a speed of 6848rpm. Its compact dimensions include a diameter of 23.1mm and a length of 18.5mm, making it suitable for various applications. The motor is equipped with 10cm long 26AWG wires with 3.5mm bullet connectors and is compatible with the BL20A-R Reversing Brushless ESC. Mounting is facilitated by two M2-0.40 holes spaced 16mm apart and two spaced 12mm apart, with additional screw holes on a 9mm circle. The motor’s wiring is versatile, allowing connections in any order, with the option to reverse direction by swapping any two wires.
- 1x FingerTech FT1806 750KV Brushless Motor
- Diameter: 23.1 mm (0.91″)
- Length (back to face): 18.5 mm (0.73″)
- Shaft Diameter: 2 mm (0.078″)
- Shaft Length: 9.6 mm (0.38″)
ZIP File
- FingerTech FT1806 750KV Brushless Motor – FT1806 STEP File
- FT1806 custom-wound high-performance brushless outrunner
- KV: 750KV
- Rated voltage: 20V (compatible with 2-4S LiPo)
- Rated current: 10A
- Motor resistance: 0.15 ohm
- Maximum current at 12V: 10A
- No-load current (with Mega Spark gearbox): 1.1A
- Recommended ESC: BL20A-R reversing brushless ESC
- Motor wires: 10cm long, 26AWG with 3.5mm bullet connectors
- Maximum power point: Voltage (12V nominal): 11.92V, Current: 10.3A, Efficiency: 58.68%, Torque: 0.0337 N.m, Power: 72W, Speed: 6848 rpm
- Mounting holes: Two M2-0.40 holes spaced 16mm, two M2-0.40 spaced 12mm, 90 degrees offset
- Rotating portion of the motor has four M2-0.40 screw holes spaced evenly on a 9mm circle
- Wiring: Connect the three ESC wires in any configuration. If the motor spins backward, swap any two wires
