- AndyMark PicoBox Servo
- Offers compatibility with standard servos
- Includes 16 tooth #25 series Ninja Star sprocket
- Weighs under 0.5 pounds
- Features reversible flanges
- Supports various servo configurations
The AndyMark PicoBox Servo is a specialized gearbox designed for FIRST Tech Challenge teams, offering a versatile and robust solution for adjusting output speed and torque in various mechanisms and drivetrains. It is engineered to integrate seamlessly with familiar building systems, featuring a base 16 mm center-to-center hole pattern that ensures compatibility and ease of use. The reversible flanges maintain this hole pattern, allowing for flexible configurations.
This gearbox is distinguished by its ability to securely mount a HiTec or Futaba standard servo, or any standard servo, providing a strong anchor point without the need for the power and torque of a motor. It includes a 16 tooth #25 series Ninja Star sprocket and a Servo Nub, making it ideal for applications requiring precise control with a standard 6 mm output shaft. The design allows for mounting the servo and output shaft on the same side, enhancing its adaptability.
Weighing under 0.5 pounds, the AndyMark PicoBox Servo is compatible with servos featuring a 24 Tooth C1 Spline, although it does not include a servo, allowing users to select the appropriate one for their specific needs. The servo cavity dimensions are 1.6 inches tall by 0.8 inches wide, accommodating a range of servo models.
- 1x 16 tooth #25 series Ninja Star sprocket
- 1x Servo Nub
- Servo cavity: 1.6 x 0.8 inches
- Includes a 16-tooth #25 series Ninja Star sprocket and a Servo Nub
- Compatible with servos featuring a 24-tooth C1 spline
- Designed to work with a 16 mm center-to-center hole pattern
- Flanges are reversible while maintaining a 16 mm hole pattern
- Utilizes the same plate style for both the input and output plates
- Allows for configurations such as mounting the servo and output shaft on the same side of the gearbox
- Weighs less than 0.5 pounds
