Description
Description
- AndyMark AM14U5 Frame Only
- Offers versatile chassis configurations
- Adapts easily for size constraints
- Includes assembly instructions and videos
- Supports diverse robotics applications
- Provides robust and flexible design
The AndyMark AM14U5 Frame Only is a versatile chassis component from the 2022 FRC Kit of Parts. This product is delivered as an unassembled kit, excluding gearboxes, belts, wheels, and motors. It is designed to offer a multitude of configuration possibilities, allowing users to adapt the frame to various perimeter, wheel, and gearbox setups. The frame can be assembled into a large square configuration, with the option to modify its dimensions to meet specific size constraints by trimming its length and width.
Built on the robust features of the previous AM14U family chassis, this frame provides flexibility and adaptability for diverse applications. The assembly process is supported by comprehensive instructions and videos, ensuring users can easily customize the frame to their requirements. This adaptability makes it suitable for a wide range of robotics projects, particularly in competitive environments where size and configuration flexibility are crucial.
Note: Ensure proper handling and assembly to avoid injury or damage.
- 1x AndyMark AM14U5 Frame Only
- 2x Inside Rail (am-3922a)
- 2x End Plate (am-3920)
- 2x Outside Plate (am-3921a)
- 2x Churro, 24.25″ Long (am-2974)
- 28x Churro Screw (am-1310)
- 4x Nut, Nylock, 3/8-16 (am-1054)
- 4x Screw, HHCS, 3/8-16 x 4.250, Gr5 Zinc (am-1297)
- 2x Hex Spacer, Plastic, 0.50″ ID, 1.124″ OD, 0.570″ Long (am-1305)
- 4x Spacer, 0.280″, 0.382″ ID, 0.518″ OD, Plastic (am-1306)
- 4x Spacer, 0.850″, 0.380″ ID, 0.75″ OD, Plastic (am-1307)
- 24x Screw, SHCS, 10-32 x 0.500 (am-1002)
- 24x Nut, Nylock, 10-32 (am-1042)
- 12x Churro, 3.375″ Long (am-2569)
- Box Size: 7 x 7 x 34 inches
- Built on the features of the previous AM14U family chassis
- Configurable into various perimeter, wheel, and gearbox configurations
- Shipped as a kit with plates for a large square configuration
- Allows users to adjust the chassis length and width for long or wide versions
- Assembly instructions and videos are available
