Description
- AndyMark AM14U5 Outside Plate
- Features versatile mounting with 0.21-inch holes
- Supports various wheel sizes and configurations
- Enhances chassis with robust aluminum construction
- Measures 32 inches for optimal chassis integration
- Enables easy customization for specific needs
The AndyMark AM14U5 Outside Plate is an integral component of the AM14U5 drive chassis, serving as the outer rail. This plate is designed with a variety of holes to support different wheel sizes, types, and configurations, as well as to accommodate support churros and bearings. Compared to its predecessor, the AM14U4 Outside Plate, this version includes additional holes to facilitate the integration of more features and components.
The top and bottom flanges of the plate are equipped with 0.21-inch holes, providing versatile mounting options for upper structures and other mechanisms. This adaptability allows for customization, enabling users to cut the plate to the desired length for specific chassis requirements. For those looking to upgrade from the AM14U4, the AM14U5 Outside Plate is essential, requiring two of these plates along with two AM14U5 inside plates.
The plate is constructed from aluminum, ensuring a balance of strength and lightweight properties, which is crucial for maintaining the efficiency and performance of the drive chassis. Its design and material make it a reliable choice for various applications in robotics and mechanical projects.
- 1x AndyMark AM14U5 Outside Plate
PDF File
- AndyMark AM14U5 Outside Plate – AM14U5 Plate PDF
- Flange length: 0.875 in
- Height: 3.06 in
- Hole pattern: 0.21 in. holes on 1.0 in. spacing
- Length: 32 in
- Material: Aluminum
- Weight: 1.532 lbs
- Width: 0.875 in
