Description
- AndyMark 6in. Pneumatic Wheel Kit
- Features a robust plastic hub
- Supports speeds up to 500 rpm
- Accommodates diverse propulsion needs
- Exhibits high traction for robotics
- Handles load capacity of 120 lbs
The AndyMark 6in. Pneumatic Wheel Kit is a high-traction wheel solution designed for competitive applications. It features a robust plastic hub that is compatible with any 150x50mm tire and inner tube, and requires two 1.125-inch ball bearings per wheel. The kit is delivered in parts, including a separate tire, inner tube, and hub halves, necessitating assembly. The hub is engineered to accommodate mounting hardware for either sprocket-driven or hub-driven configurations, making it versatile for various propulsion needs.
This wheel is particularly suited for driving robots or wheelchairs, with a design optimized for ground contact and propulsion via a gearbox at speeds up to 500 rpm, translating to approximately 13 feet per second. In certain applications, the wheel can be used as a shooter, capable of spinning at high speeds up to 5,000 rpm when properly balanced and securely mounted. However, users should be aware that the valve stem’s off-center position may cause wobbling at higher speeds.
Note: Exercise caution during assembly to avoid pinching the inner tube between the hub halves, as this may lead to punctures and air leaks.
- 1x AndyMark 6in. Pneumatic Wheel Kit
- 1x Tire for 6 Inch Pneumatic Wheel (Metric Size 150x50mm), am-2474
- 1x Inner Tube for 6 Inch Pneumatic Wheel, with 45 Degree Stem (for 150x50mm Tire), am-2475
- Hub Assembly for 6 inch Pneumatic Wheel, which includes two black plastic hub halves and six 4-40 x1 Pan Head Phillips thread rolling screws
- Diameter: 6.00 inches
- Width: 2.190 inches
PDF File
- AndyMark 6in. Pneumatic Wheel Kit – PDF
ZIP File
- AndyMark 6in. Pneumatic Wheel Kit – STEP
- Bolt pattern: 6 holes, 0.20 diameter on 1.875 in. diameter bolt circle
- Bore: 0.960 in. through hole, with 1.125 in. x 0.375 in. deep bearing pockets
- Load capacity: 120 lbs
- Material: Black polycarbonate, gray rubber
- Maximum pressure: 35 psi
- Tread width: 1.39 in
- Valve stem: May protrude up to 0.25 in. from the hub
